Designing Your Neural Induction and Differentiation Workflow

Introduction

Neural induction is the first step in the specification of human pluripotent stem cells (hPSCs) to a neuroectodermal fate. In vivo, neural induction is initiated through the disinhibition of TGF-β and BMP signaling that occurs through the action of patterning factors released in the developing embryo1. Induction of cultured human embryonic stem (ES) cells and induced pluripotent stem (iPS) cells to a neural fate involves mimicking these developmental cues in vitro.

This Tech Tip will walk you through practical considerations to help you select the ideal in vitro neural induction workflow to generate neural progenitor cells (NPCs), including medium choice, protocol format, and options for further expansion, cryopreservation, and differentiation of NPCs to downstream neural cell types.


Choosing a Medium: STEMdiff™ Neural Induction Medium vs. STEMdiff™ SMADi Neural Induction Kit

STEMdiff™ Neural Induction Medium (NIM) is a serum-free medium for the neural induction of hPSCs, including human ES and iPS cells. The cultures generated will primarily consist of central nervous system (CNS)-type NPCs, which express PAX6, SOX1, and Nestin. A smaller population of neural crest cells may also be present. If patterning factors are unwanted in your cell culture application, STEMdiff™ NIM is an appropriate choice for neural induction.

Note: If generation of neural crest cells is your primary objective, using STEMdiff™ Neural Crest Differentiation Kit is recommended. For hard-to-differentiate cell lines, EasySep™ Release Human PSC-Derived Neural Crest Cell Positive Selection Kit may be used to further purify the resulting cells.

Dual SMAD inhibition (SMADi) directs efficient neural induction of hPSCs by inhibiting TGF-β- and BMP-dependent SMAD signaling2. STEMdiff™ SMADi Neural Induction Kit combines STEMdiff™ NIM with STEMdiff™ SMADi Neural Induction Supplement to significantly improve the efficiency of neural induction, even in hard-to-differentiate cell lines. Because this method results in a highly pure population of CNS-type NPCs, SMADi supplementation is strongly recommended, particularly if you will be further differentiating your NPCs to downstream cell types such as neurons or astrocytes.


Choosing a Protocol Format: Embryoid Body vs. Monolayer Protocols

Neural induction of hPSCs may be achieved using either an embryoid body (EB) or monolayer culture format, both of which are outlined in the Technical Manual for Generation and Culture of Neural Progenitor Cells Using the STEMdiff™ Neural System (Document #10000005588). Both protocol options have advantages, and either (or both) may be suitable for your research. Please refer to the table below for key considerations:

Embryoid Body (EB)
Monolayer
Main Benefits
Robust for difficult-to-differentiate or new/untested cell lines

Typically results in less variability between cell lines
Simple and straightforward

Typically results in less variability between replicates from the same cell line
AggreWell™ Microwell Culture Plates Required (Catalog #34811)
Yes
No
STEMdiff™ Neural Rosette Selection Reagent Required (Catalog #05832)
Yes
No
Method to Confirm Neural Induction
Immunostaining or flow cytometry to confirm % neural marker expression

Day 8 Checkpoint: Visual inspection of rosette formation
Immunostaining or flow cytometry to confirm % neural marker expression
Compatibility with Upstream hPSC Maintenance Media
Compatible with hPSCs cultured in mTeSR™1 and mTeSR™ Plus (SMADi not essential, but recommended)

Compatible with hPSCs cultured in TeSR™-E8™ (SMADi highly recommended)
Compatible with hPSCs cultured in mTeSR™1 and mTeSR™ Plus (SMADi recommended)

Compatible with hPSCs cultured in TeSR™-E8™ (SMADi highly recommended)
Compatibility with Downstream Differentiation Kits
STEMdiff™ Forebrain Neuron Differentiation Kit (Catalog #08600) and STEMdiff™ Forebrain Neuron Maturation Kit (Catalog #08605)

STEMdiff™ Midbrain Neuron Differentiation Kit (Catalog #100-0038) and STEMdiff™ Midbrain Neuron Maturation Kit (Catalog #100-0041)

STEMdiff™ Astrocyte Differentiation Kit (Catalog #100-0013) and STEMdiff™ Astrocyte Maturation Kit (Catalog #100-0016)

BrainPhys™ hPSC Neuron Kit (Catalog #05795)
  • May be combined with additional patterning factors as desired to customize your neuronal differentiation

Related Protocols


Important Checkpoint: Characterization of hPSC-Derived NPCs

After completing the neural induction protocol, it is important to establish that the induction was successful by characterizing your resulting NPCs. Although NPC morphology can provide information about culture health, it is not a reliable method for confirming neural induction and purity. To assess the efficiency of neural induction, immunocytochemistry may be performed for the following markers to determine the percentage of cells expressing each:

Marker
Suggested Antibody Clone
Expected Expression*
PAX6 (early neural progenitor marker)
Poly19013 (BioLegend Catalog #901301)
≥ 80 - 90%
SOX1 (neural progenitor marker)
Polyclonal (R&D Systems Catalog #AF3369)
≥ 80 - 90%
Nestin (pan-neural marker)
≥ 80 - 90%
OCT4 (undifferentiated hPSC marker)
3A2A20 (Catalog #60093)
Negligible
SOX10 (neural crest marker)
A-2 (Santa Cruz Catalog #sc-365692)
≤ 10%

*The % expression levels noted in this table are expected with conventional use of the STEMdiff™ SMADi Neural Induction Kit.

It is recommended to perform staining for at least two of the three neural markers listed above (e.g. PAX6 and SOX1, PAX6 and Nestin, or SOX1 and Nestin). Nestin should not be used on its own to evaluate induction efficiency because it may also be expressed by neural crest cells, the most common non-NPC cell type found in neural induction cultures.

For information about assessing neural/ectodermal marker expression by flow cytometry, please refer to the following Tech Tip: The STEMdiff™ Trilineage Differentiation Kit: Assessing Differentiation to Three Germ Lineages.

Increasing Workflow Yield: NPC Expansion

After neural induction, you may further maintain and expand your NPCs in STEMdiff™ Neural Progenitor Medium (NPM) for at least 10 passages with good marker expression and minimal spontaneous neuronal differentiation. NPCs will expand 3- to 5-fold per passage.

Important considerations for NPC expansion:

  • If you will be performing downstream differentiation to neurons, we recommend limiting the number of NPC passages in STEMdiff™ NPM to less than five to promote the best neuronal differentiation efficiency. This is not to say that higher passage numbers won't work, but if poor efficiency is observed with high-passage NPCs, a 'younger' batch of NPCs may be worth trying.
  • Periodically recharacterize neural marker expression (PAX6, SOX1, Nestin) if multiple passages have been performed before proceeding to downstream differentiation or assays.
  • Ensure that at each passage, cells are seeded at the high density recommended in the manual (e.g. at least
    1.25 x 105 cells/cm2). High densities are critical to maintain NPCs in a proliferative state and prevent spontaneous differentiation from occurring.
  • If you observe poor viability after passaging, 10 μM ROCK inhibitor Y-27632 may be included in the medium during the plating step.

Increasing Workflow Flexibility: NPC Cryopreservation and Thawing

Banking your NPCs at a midpoint in your experimental protocol offers flexibility and allows you to standardize your downstream experiments by starting with the same initial NPC population. After neural induction, NPCs may be cryopreserved using either STEMdiff™ Neural Progenitor Freezing Medium or CryoStor® CS10 following the instructions outlined in section 6.3 of the Technical Manual (Document #10000005588).

Important considerations for NPC thawing:

  • If thawing for immediate use in a downstream application:
    • Cryopreserved NPCs should be thawed into STEMdiff™ NPM. Allow the cells to recover for one day prior to changing to the desired downstream medium.
    • Seeding density upon thawing may need to be optimized to yield the ideal density for the application.
  • If thawing for subsequent NPC expansion:
    • Cryopreserved NPCs should be thawed into STEMdiff™ NPM and maintained until they are ready to be passaged (typically 5 - 7 days).
    • Suggested seeding density upon thawing is 200,000 live cells/cm2.
  • Recharacterize neural marker expression (PAX6, SOX1, Nestin) after thawing.
  • Avoid repeated freezing and thawing of the same batch of cells. Try to bank NPCs at relatively early passage numbers and use these stocks for experiments.
  • Post-thaw viability is typically 70 - 85%. If you observe poor NPC recovery after plating, 10 μM ROCK inhibitor Y-27632 may be included in the medium during the plating step.

Resources for hPSC-Based Neural Induction and Differentiation

Browse scientific posters, webinars, and technical tips for culturing neural cells from hPSCs.

Explore Now >

Protocol Considerations for Downstream Differentiation to Neurons and Astrocytes

If you plan to further differentiate your cells into neurons or astrocytes, there are multiple culture workflow options available. Please refer to the following table for details:

Recommended Workflow
Begin the STEMdiff™ forebrain neuron differentiation on
Day 12 - 13 of the embryoid body neural induction protocol or immediately following the 18- to 21-day monolayer neural induction protocol, as outlined in the STEMdiff™ Forebrain Neuron Product Information Sheet (Document #10000005464).
Begin the STEMdiff™ midbrain neuron differentiation on Day 6 of the embryoid body neural induction protocol or immediately following the 18- to 21-day monolayer neural induction protocol, as outlined in the STEMdiff™ Midbrain Neuron Product Information Sheet (Document #10000007220).
Begin the STEMdiff™ astrocyte differentiation on Day 12 - 13 of the embryoid body neural induction protocol or immediately following the 18- to 21-day monolayer neural induction protocol, as outlined in the STEMdiff™ Astrocyte Product Information Sheet (Document #10000006879).
Alternative Workflow Options*
Perform the entire 17- to 19-day embryoid body protocol or the entire 18- to 21-day monolayer protocol, as outlined in the STEMdiff™ Neural Induction Technical Manual, followed by NPC expansion (up to 5 passages) and/or cryopreservation prior to beginning STEMdiff™ forebrain neuron differentiation.
Perform the entire 18- to 21-day monolayer neural induction protocol, as outlined in the STEMdiff™ Neural Induction Technical Manual, followed by NPC expansion (up to 5 passages) and/or cryopreservation prior to beginning STEMdiff™ midbrain neuron differentiation.

Note: It is not recommended to initiate the midbrain neuron differentiation following the full 17- to 19-day embryoid body neural induction.
Perform the entire 17- to 19-day embryoid body protocol or the entire 18- to 21-day monolayer protocol, as outlined in the STEMdiff™ Neural Induction Technical Manual, followed by NPC expansion and/or cryopreservation prior to beginning STEMdiff™ astrocyte differentiation.

*The alternative workflow options listed above are compatible with NPCs derived using the STEMdiff™ Neural Induction System, but reduced downstream differentiation efficiency may be observed compared to the recommended workflow.

Still unsure which workflow is right for your research? We can help. Contact us by phone or email or use the LiveChat function on this page to discuss your specific needs and applications.
